Smit Rotterdam

General.
The Smit Rotterdam, as well as her sistership Smit London, is a 22.000 ihp ocean-going multi-purpose tug and has been designed to perform towages with heavy objects over long distances for the offshore industry, for salvage assistance to ships in distress and to carry out anchor-handling operations. The names are recently (1998) changed in Smitwys Rotterdam and Smitwys London.

Propulsion

The propulsion machinery consists of two Stork-Werkspoor TM 410 turbocharged, four stroke, single acting, unidirectional diesel engines. Each engine drives a fourblade variable pitch propeller turning in a fixed nozzle. The machinery may be remotely controlled from the bridge deck as well as from an airconditioned control room in the engine room.

Manoeuvrability

The twinscrew-arrangment combined with two rudders and a powerful 800 hp bow-thruster guarantees excellent manoeuvrability. The wheelhouse is situated amidships which allows an excellent view over the aftdeck as well as forward, for bridge controlled manoeuvring, which is possible from four positions.

Dimensions:

Length o.a.
74.75 m
Beam o.a.
15.68 m
Depth
7.60 m
Draft (max.)
6.40 m

Port of registry: Rotterdam NL

Callsign : P.H.P.O.
Built by: De Merwede, Hardinxveld-Giessendam NL
Year of construction 1975
Max.speed: 17 knots.


Have also a look at Smit-Internationals website.
Click here for more photos of the Smit Rotterdam taken by Hauke Behn.
